• 產品特點
• 兼容多種采樣方式:模塊下行可接干簧管采樣、磁阻采樣、霍爾采樣、無磁采樣基表，計量精準;
• 遠程實時抄控:可通過集采器遠程實時抄表、控閥;
• 定時上傳功能:默認6小時上傳一次;
• 觸發實時上傳:可通過觸發磁開關，實時上傳數據;
• 采樣故障檢測功能:當采樣傳感器發生故障時，表具上傳故障信息閥門控制:可遠程或者手持設備控制水表閥門的開和關;
• 機電同步:可做無磁采樣與光電采樣。
• 攻擊關閥功能:具有防外部電、磁攻擊功能，當采樣受到外部電、磁等攻擊時，表具可以自動關閉閥門;
• 閥門故障檢測功能:檢測閥門開、關是否到位，上傳閥門狀態信息;洗閥功能:閥門定期開關，防銹死。

Product features
Compatible with multiple sampling methods: the module can be connected to reed sampling, reluctance sampling, Hall sampling, and non-magnetic sampling base meters for precise measurement;
Remote real-time meter reading and control: It is possible to remotely read meters and control valves in real-time through the centralized collector;
Timed upload function: defaults to uploading every 6 hours;
Trigger real-time upload: Data can be uploaded in real time by triggering the magnetic switch;
Sampling fault detection function: When the sampling sensor fails, the meter uploads fault information. Valve control: The opening and closing of the water meter valve can be controlled remotely or by handheld devices;
Electromechanical synchronization: can perform both non-magnetic sampling and optoelectronic sampling.
Attack valve closing function: It has the function of preventing external electrical and magnetic attacks. When the sampling is attacked by external electrical and magnetic attacks, the meter can automatically close the valve;
Valve fault detection function: detects whether the valve is open and closed properly, and uploads valve status information; Valve washing function: The valve is opened and closed regularly to prevent rust.

產品參數（中文） Product parameters（English）	參數值（中文） Parameter values（English）
調制方式 Modulation	LoRa
工作電壓 Working voltage	2.7~3.6V
靜態功耗 Static power consumption	<10uA
發射電流 Emission Current	<110mA
接收電流 Receiving Current	<15mA
發射功率 Transmission power	<20dBm
信號靈敏度 Signal sensitivity	-128±1dBm
工作溫度 Operation temperature	-20~75°C
工作濕度 Working humidity	0~95%,無冷凝 No condensation
喚醒時間 Wake-up time	實時喚醒 Real time wake-up
無線阻抗 Wireless impedance	50Ω
工作頻段 Working frequency band	470-510MHz、868-915MHZ
通訊距離 Communication Distance	2-5KM
